Opis
EIKON EKJJ GUITAR WIRELESS
EIKON EKJJ EKJ&J is a UHF wireless guitar system that provides high quality and reliable signal transmission. EKJ&J comes with 3 units: EKJ J compact “connector format” transmitter, compact EKJ&J “connector format” receiver and USB to USB-C charging cable
Proel Eikon EKJJ bežični gitarski UHF sistem. Eikon EKJJ sistem ima 3x jedinice – kompaktni EKJ&J transmiter veličine konektora, kompaktni EKJ&J receiver, također veličine konektora i USB – USB C kabel punjač. Istovremeno je moguće koristiti do 6x sistema bez ometanja prijema signala. Kompaktan po dimenzijama, praktičan, kvalitetan, povoljan. Više tehničkih detalja u nastavku.
Specifikacija Eikon EKJJ bežični gitarski UHF sistem:
UHF 863 – 865 MHz frequency band
Quartz locked modulation mode
Up to 30 meters range
Built in 3.7V/500mA lithium battery
5V USB charging cable included
Up to 4 hours autonomy
Up to 6 systems usable in the same location
EKJ&J – UHF PLL 16 Channel Transmitter
RF Channels
16 frequency presets
RF Frequency Band
UHF: 863-865 MHz
RF Frequency Stability
±0,002%
RF Oscillation Mode
Quartz locked
RF Modulation Type
Wideband FM Stereo
RF Output Power
10mW
Sub-harmonic
< 40 dB
Operating current
120 mA
Operating Time
3 to 5 hrs
Operating Power Supply
3.7 V / 500 mA – built-in Lithium battery
Charging mode
USB charging 5V – type C connector
Charging time
3 hours
Weight
0.05 Kg
EKJ&J –UHF PLL 16 Channels Receiver
RF Channels
16 frequency presets
RF Frequency Band
UHF: 863-865 MHz
RF Frequency Stability
±0,005%
RF Oscillation Mode
Quartz locked
RF Modulation Type
Wideband FM Stereo
RF Receiving Sensitivity
< -98 dBm
RF Receiving range
15 to 30 meters depending on used band conditions
Audio dynamic range
106 dBm
THD Distortion
< 0.5%
S/N Ratio
> 102 dBA
Audio output connector
6.3 mm Mono Jack
Output Power Max (continuous)
400 mW
Operating current
80 mA
Operating Time
5 hours
Operating Power Supply
3.7 V / 500 mA – built-in Lithium battery
Charging mode
USB charging 5V – type C connector
Charging time
3 hours
Weight
0.05 Kg
EKJ&JA – UHF PLL 50 Channel Transmitter
RF Channels
50 frequency presets
Rf Frequency Band
UHF: 512 – 541,7 MHz
RF Frequency Stability
±0,002%
RF Oscillation Mode
Quartz locked
RF Modulation Type
Wideband FM Stereo
RF Output Power
10mW
Sub-harmonic
< 40 dB
Operating current
120 mA
Operating Time
3 to 5 hrs
Operating Power Supply
3.7 V / 500 mA – built-in Lithium battery
Charging mode
USB charging 5V – type C connector
Charging time
3 hours
Weight
0.05 Kg
EKJ&JA –UHF PLL 50 Channels Receiver
RF Channels
50 frequency presets
RF Frequency Band
UHF: 512 – 541,7 MHz
RF Frequency Stability
±0,005%
RF Oscillation Mode
Quartz locked
RF Modulation Type
Wideband FM Stereo
RF Receiving Sensitivity
< -98 dBm
RF Receiving range
15 to 30 meters depending on used band conditions
Audio dynamic range
106 dBm
THD Distortion
< 0.5%
S/N Ratio
> 102 dBA
Audio output connector
6.3 mm Mono Jack
Output Power Max (continuous)
400 mW
Operating current
80 mA
Operating Time
5 hours
Operating Power Supply
3.7 V / 500 mA – built-in Lithium battery
Charging mode
USB charging 5V – type C connector
Charging time
3 hours
Weight
0.05 Kg
