Opis
Proel DIVA12A – 2-way Active loudspeaker system. – 35” compression driver. – 90° x 60° horn. – 12” woofer with 2” VC.
1000 W peak Class D amplifier with SMPS. – DSP with FIR filters and 5 DSP presets.
3 Ch mixer with Stereo Bluetooth – SPL MAX: 127 dB. – Frequency range: 50 Hz – 20 kHz
Specifikacija Proel DIVA 12A aktivna zvučna kutija
System type 2-way vented enclosure
High Frequency Device 1’’ compression driver with 1.35″ voice coil and titanium diaphragm
Low Frequency Device 12″ woofer with 2″ VC
Angular Coverage 90° H x 60° V
Total Peak Power 1000 W
HF Amplifier Continuous Power 100 W Class AB
LF Amplifier Continuous Power 400 W Class D
Power Supply SMPS
System Processing DSP
Frequency Response 50 Hz – 20 kHz
Max SPL 127 dB
Inputs 2 x MIC/LINE (COMBO), 1 X STEREO LINE (MINIJACK), 2 x USB WIRELESS
Outputs 1 x selectable MIX OUT / CH1 LINK (M-XLR)
Controls CHANNEL LEVEL, INPUT SELECTOR, HIGH & LOW EQ, ROTARY PUSH ENCODER, COLOR LCD
Bluetooth Version 5.0, Audio Streaming, STEREO LINK (TWS)
Power Supply 100-120 V~ or 220-240 V~ at 50/60 Hz with self-switch
Rated Consumption* 300 W
Floor Monitor Angle 45°
Flying System 4 x M10 – top/bottom
Cabinet Material Polypropylene
Handles 1 x top, 1 x side
Mounting Pole 1 x bottom
Dimensions (W x H x D) 364 x 617 x 346 mm
Weight 16.0 kg
